FXT00V-AS16 4 Stroke Engine FXT00V

FXT00V-AS16 Lubrication-Equipment Diagram

Exploded parts diagram of the Lubrication-Equipment of a Kawasaki FXT00V-AS16 engine, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 1310713107-0749Not stocked
    SHAFT×1
  • 1327113271-7034Price
    PLATE,ROTOR-PUMP×1
  • 1407514075-0036Not stocked
    CAP-ASSY×1
  • 1615416154-7007Price
    ROTOR-PUMP,IN×1
  • 16154A16154-7008Price
    ROTOR-PUMP,OUT×1
  • 4906549065-7004Price
    FILTER-OILReplaced by 49065-0718×1
  • 49065A49065-0724Price
    FILTER-OILReplaced by 49065-0734×1
  • 5905159051-7026Price
    GEAR-SPUR,OIL-PUMP×1
  • 5923159231-7011Not stocked
    FILLER×1
  • 9204392043-7003Not stocked
    PIN×2
  • 9206692066-0774Price
    PLUG×2
  • 92066A92066-7003Not stocked
    PLUG×0
  • 9214092140-7003Price
    BALL,STEEL,13/32Replaced by 92140-0029×1
  • 9214592145-7046Price
    SPRING×1
  • 9215392153-7007Price
    BOLT,FLANGED,6X16×1
  • 92153A92153-7043Not stocked
    BOLT,6X12×3
  • 670670D2016Price
    O RING,16MM×3
