FXT00V-AS20 4 Stroke Engine FXT00V

FXT00V-AS20 Fuel-Tank / Fuel-Valve Diagram

Exploded parts diagram of the Fuel-Tank / Fuel-Valve of a Kawasaki FXT00V-AS20 engine, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 1106511065-7005
    $0.79
    CAPReplaced by 11065-1437×1
  • 4901949019-0027
    $8.39
    FILTER-FUELReplaced by 49019-0031×1
  • 9217092170-2009
    $2.03
    CLAMPReplaced by 92173-1582×3
  • 9219292192-7168Not stocked
    TUBE,6.35X12.7X100×1
  • 92192A92192-7179Not stocked
    TUBE,6.35X12.7X285×1
