FXT00V-AS09 4 Stroke Engine FXT00V

FXT00V-AS09 Label Diagram

Exploded parts diagram of the Label of a Kawasaki FXT00V-AS09 engine, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 5601456014-0005
    $1.85
    EMBLEM×1
  • 5603356033-7001
    $1.20
    LABEL-MANUALReplaced by 56033-1502×1
  • 5607056070-7001Not stocked
    LABEL-WARNING×0
  • 56071A56071-0216
    $2.21
    LABEL-WARNINGReplaced by 56071-1170×1
